FBR FGP 75/2 LX TC SI

SKU 3G-FBR-00081

Brand
FBR
Item
FGP 75/2 LX TC SI
Category
Burners & Combustion

Technical Specifications

FBR
Weight
52 kg
stage
Serie low nox
fuel type
Light oil
nozzle mm
250
description
Light-oil burners two stages Low NOx (NOx < 120 mg/kWh).
fan motor w
1.5
power kw max
1186
power kw min
333
flow kg h max
100
flow kg h min
28
ip protection
IP 40
noisiness dba
82-83.6
pump motor kw
0.37
electrical supply
3
power supply info
- 50Hz
current absorption a
0.82
thermal power mcal h
286.4/510-1020
nominal electric power w
2.1
max combustion air temp c
60
Sign in to view pricing
Create a free account to submit your RFQ and download technical documents.

Solutions Engineering

Need guidance on product selection or system design?
Contact Our Engineering Team
Authorized FBR Distributor
3G Electric (S) Pte. Ltd. — Singapore

Product Description

FBR FGP 75/2 LX TC SI is a two-stage light-oil diesel burner engineered for industrial heating applications. This Italian-manufactured unit delivers thermal power from 286.4 to 1,020 mcal/h with minimal environmental impact, maintaining NOx emissions below 120 mg/kWh. Featuring a 250mm nozzle, 1.5kW fan motor, and maximum combustion air temperature of 60°C, it operates efficiently across a 333-1,186 kW power range. The burner carries IP 40 protection and generates 82-83.6 dBA noise levels. Ideal for industrial boilers and process heating systems, it is available from 3G Electric Singapore.
