Kobold logo

Kobold

GermanyMeasurement & Detection

Kobold manufactures turbine and variable-area flow meters for industrial liquid and gas measurement. The product range spans compact low-flow units (2–20 l/h) through mid-range industrial applications (up to 400 l/h and beyond), with models available for water, oils, and other process liquids. Kobold flow meters use mechanical turbine elements or float-column designs to deliver direct flow indication and repeatable accuracy across process-control environments including cooling loops, HVAC systems, chemical dosing, and utility monitoring. These meters are manufactured to withstand industrial duty conditions—rated for working pressures up to 16 bar in typical configurations and sized for nominal pipe connections from 10 mm to 25 mm. Kobold designs emphasize mechanical simplicity: turbine rotors spin in response to flow, with output signals transmitted mechanically or electronically depending on the model variant. Models with rod guiding (such as LZT-25S16) provide stable float position and improved readability in vertical or horizontal mounting. Lead times and inventory are managed from Singapore; technical datasheets and application guidance are available upon request for specification validation and sizing.

20
In Collection
12,386
Full Catalog
1 Day
Quote Response
Germany
Origin
Worldwide Shipping
Air & sea freight
Datasheets on Request
Technical specs & drawings
1-Day Quote Response
Singapore-based team
Show
Page 1 of 1
20 products

About Kobold

Kobold manufactures turbine and variable-area flow meters for industrial liquid and gas measurement. The product range spans compact low-flow units (2–20 l/h) through mid-range industrial applications (up to 400 l/h and beyond), with models available for water, oils, and other process liquids. Kobold flow meters use mechanical turbine elements or float-column designs to deliver direct flow indication and repeatable accuracy across process-control environments including cooling loops, HVAC systems, chemical dosing, and utility monitoring. These meters are manufactured to withstand industrial duty conditions—rated for working pressures up to 16 bar in typical configurations and sized for nominal pipe connections from 10 mm to 25 mm. Kobold designs emphasize mechanical simplicity: turbine rotors spin in response to flow, with output signals transmitted mechanically or electronically depending on the model variant. Models with rod guiding (such as LZT-25S16) provide stable float position and improved readability in vertical or horizontal mounting. Lead times and inventory are managed from Singapore; technical datasheets and application guidance are available upon request for specification validation and sizing.

Common Applications

  • Cooling-water loops in industrial machinery — Kobold LZT 0804M/0806M for precise return-flow monitoring and control in closed-circuit cooling systems.
  • HVAC chilled-water distribution — Kobold LZT-25S16 with rod guiding for stable measurement in vertical riser and horizontal branch piping.
  • Chemical process dosing — Kobold LZT 0801M or LZT 15S25 for accurate metering of additives, inhibitors, or treatment chemicals into main process streams.
  • Water-treatment plant flow monitoring — Kobold LZT 15S40 turbine meters for utility-scale flow logging and balancing across filtration and recirculation loops.
  • Compressed-air and gas flow indication — Kobold gas-capable variants rated for low-pressure air and inert-gas pilot systems in burner and valve control circuits.
Origin: Manufactured in Germany

Related brands we carry

Comparable manufacturers in the same product category.

Afriso
Aquametro
Bacharach
Beck
DTekGaz
Dwyer

Frequently asked questions

Common questions about Kobold from 3G Electric.

What is the pressure rating on Kobold LZT series flow meters?

Kobold LZT turbine meters are rated to 16 bar (230 psi) in standard configuration. Working pressure depends on connection size and valve integration; verify the nameplate or datasheet for your specific model. Higher-pressure variants may be available upon request.

Can Kobold LZT flow meters be used vertically, and does rod guiding matter?

Yes. Vertical mounting is common in process loops. Models with rod guiding (e.g., LZT-25S16) stabilize the float column and reduce drift caused by flow pulsation or vibration. Models without rod guiding work vertically but perform best in low-turbulence, stable flow conditions.

What is the difference between Kobold LZT 0801M and LZT 0804M models?

The primary difference is measuring range: LZT 0801M covers 2–20 l/h and 10–100 l/h variants, while LZT 0804M ranges 4–40 l/h. Both are compact water flow meters suitable for low-flow industrial applications. Choice depends on your process flow rate and resolution requirements.

Do Kobold flow meters with integrated valves (e.g., LZT 0804M/V) require separate shutoff?

Models designated /V include an integrated metering and shutoff valve, reducing piping and component count. The valve allows local on-off control without additional isolation blocks. Flow adjustment is typically manual; confirm valve setting range in the product datasheet.

What flow range should I choose for my application: LZT 15S25 or LZT 15S40?

LZT 15S25 measures 25–250 l/h; LZT 15S40 measures 40–400 l/h. Select based on your process nominal flow rate. Best accuracy occurs near the upper 80% of the meter's range. Undersized meters (flow below 20% of span) reduce accuracy.

Does 3G Electric supply Kobold products?

Yes — 3G Electric (S) Pte. Ltd. supplies Kobold products. We stock the Kobold catalog and supply genuine factory-original products with full manufacturer warranty and technical support.
