What is a Beckett CG10 gas burner used for?

The Beckett CG10 is a direct spark ignition burner rated 300–1,200 MBH, designed for commercial heating systems, steam generation, and food processing applications. Its compact aluminum construction suits industrial and hospitality environments across Southeast Asia.

What are the specifications of the Beckett CG10 burner?

The CG10 features a 1/3 HP motor at 3450 RPM, 120V / 60 Hz single-phase AC power, and operates on natural gas at 0.6 specific gravity typical. Flame detection uses flame rod rectification as standard, with UV scanner available as an option.

Where can I buy a Beckett CG10 gas burner in Singapore?

3G Electric, an authorized Beckett distributor established in 1990, supplies the CG10 burner to Singapore and the region. We handle full logistics, customs clearance, and delivery. Contact us for lead times and technical support tailored to your application.

How do I select the right burner for my heating system?

Match your system's heat demand in MBH to the burner's 300–1,200 MBH range. Verify your facility's gas supply pressure and quality (0.6 specific gravity typical for natural gas). Confirm available electrical service: 120V / 60 Hz single-phase, or request optional 240V or 50 Hz configuration from your supplier.

Beckett: CG10 Gas Burner 300 to 1,200 MBH | AC Power - Burners

Technical Documents

(12)

Complete Solution

Need installation, maintenance, or a bundled quote?

Our engineers can help with product selection, system design, installation, and ongoing service — all from one partner.

Product + Service Bundle QuoteQuote

Quick Inquiry

BeckettBurners

Available

Beckett: CG10 Gas Burner 300 to 1,200 MBH | AC Power

Name: Beckett: CG10 Gas Burner 300 to 1,200 MBH | AC Power
Brand: Beckett
SKU: 3G-BKT-00021
Availability: BackOrder

SKU 3G-BKT-00021

Brand

Beckett

Item

Beckett: CG10 Gas Burner 300 to 1,200 MBH

Technical Specifications

Beckett

Motor

1/3 HP, 3450 RPM

Voltage

120V / 60 Hz, Single Phase

Natural Gas

0.6 Specific Gravity Typical

Flame Detection

Flame Rod Rectification (Standard), UV Scanner (Optional)

Optional Voltages

50 or 60 Hz, 240V Single Phase

View Full Spec Sheet

Worldwide Shipping

Create a free account to submit your RFQ and download technical documents.

Pair with a Service

Installation & Commissioning

Professional setup and verification by our technicians

View

Ongoing Maintenance Plan

Scheduled preventive maintenance for this equipment

View

Product + Service Bundle

Combined quote for equipment, installation, and service

View

Solutions Engineering

Need guidance on product selection or system design?

Contact Our Engineering Team

Beckett Products

3G Electric (S) Pte. Ltd. — Singapore

Product Description

Beckett CG10 gas burner delivers 300–1,200 MBH output for commercial heating, steam generation, and food processing. Direct spark ignition with flame detection in a compact, durable aluminum design.

Key Features

Direct spark ignition system with flame rod rectification
Cast aluminum housing for robust, quiet operation
1/3 HP motor at 3,450 RPM
120V/60Hz single-phase standard; optional 240V or 50Hz
Ventless gas train configuration included
Removable gas gun assembly for simplified maintenance
Flexible gas train connection (right or left hand)
UL/cUL and CSD-1 certified for safety compliance
300–1,200 MBH output range for light commercial/industrial use
UV scanner flame detection available as upgrade
Remote-mounted control panel option
